M23 6 Pin Double Ended Male To Female Cordset
Premier Cable M23 6 Pin Double Ended Male to Female Cordset for Servo Power Applications
M23 6 Pin Power Cordset Male to Female Molded Extension Cable for Servo Drives
High-Flex M23 6 Pin Male to Female Cordset IP67 Molded Cable for Moving Equipment
M23 6 Pin Male to Female Cordset for Robotics, Motors, and Industrial Automation
M23 6 Pin Double Ended TPU Cordset Drag Chain & Torsion Resistant Industrial Cable
M23 6 Pin Ob Ended Txiv neej Rau Poj Niam Cordset
Premier Cable Co., Ltd yog ib qho ntawm cov ua m23 6 pin ob tug txiv neej rau poj niam cordset manufacturers thiab lwm tus neeg nyob hauv Suav teb. Txais tos rau kev lag luam wholesale zoo customized khoom ntawm luv nqi los ntawm peb lub hoobkas. Tiv tauj peb rau kev hais lus thiab qauv dawb.
CovM23 6 Pin Ob Qhov Kawg Txiv Neej rau Poj Niam Cordsetyog tsim los raufais fab kis tau tus mob thiab txhim khu kev qha interconnectionnyob rau hauv kev xav tau kev lag luam ib puag ncig.
Featuring ibmolded connector tsimthiab ahnyav -lub luag haujlwm TPU tsho, no cable kom paub meejruaj ntseg hluav taws xob tiv tauj, mechanical zog, thiablub neej ua haujlwm ntevnyob rau hauv nruam txav.
Engineered rauservo motors, drives, thiab tswj kev txav chaw, lub rooj sib txoos muab kev tiv thaiv zoo tiv thaivkev vibration, roj, puas, thiab torsion, ua rau nws zoo tagnrho raurobotic caj npab, conveyors, thiab automated ntau lawm kab.
Specifications
| Khoom npe | M23 6-Pin Fais Fab Extension Cable|Moulded Txiv neej rau poj niam nrog TPU Jacket |
| Daim duab No. | PCM{0}}S-0647 |
| Hom Connector | M23 txiv neej rau M23 poj niam, molded |
| Pin suav | 6 - pin |
| Hom kab | (1P × 1.5mm² + D + AL + MY) × 1C + 4C × 2.5mm² + F + Tsis yog-woven + B + Tsis yog-woven |
| Cable ntev | 5m lossis customized |
| Cable txoj kab uas hla | 14.5mm 3 |
| Cable tsho | Dub TPU (Thermoplastic Polyurethane) |
| Cable nta | Drag saw & torsion resistant, roj- thiab hnav-resistant |
| Rated voltage | Mus txog 600 V |
| Rated tam sim no | Mus txog 18 A |
| Ua haujlwm kub | -40℃rau +85 degree |
| Kev tiv thaiv qib | IP67 thaum sib yuav |
| Kev kho kom haum | Ntev, pinout, thiab lub kaum sab xis kev taw qhia muaj raws li qhov kev thov |
FAQ
Q1: M23 6-pin cable feem ntau siv rau dab tsi?
A1: Nws feem ntau yog siv rau kev xa hluav taws xob hauv servo motors, actuators, thiab drives, qhov twg ntau tus neeg xyuas pib tuav cov dej ntws ntau dua rau kev sib txuas sib txuas.
Q2: Qhov no M23 txuas ntxiv cable puas tuaj yeem ua haujlwm txuas ntxiv?
Q2: Yog. Lub tsho TPU thiab rub cov hlua tsim tso cai rau lub cable ua kom ntseeg tau raws li qhov txuas txuas ntxiv lossis sib tw.
Q3: Dab tsi yog qhov zoo ntawm M23 molded connectors?
Q3: M23 molded connectors muab IP67 sealing, strain nyem, thiab kev co tiv thaiv kev co - zoo tagnrho rau hnyav Hoobkas ib puag ncig.
Q4: Qhov no puas tuaj yeem hloov kho M23 6-pin fais fab cable?
Q4: Yog lawm. Cable ntev, xaim layout, tsho xim, thiab connector orientation tuaj yeem ua tau raws li koj qhov kev xav tau.
Cim npe nrov: m23 6 tus pin ob leeg kawg txiv neej rau poj niam cordset, lwm tus neeg, manufacturers, hoobkas, customized, lag luam wholesale, quotation, dawb qauv
