Muaj M12 rau RJ45 Ethernet thiab EtherCat Pane Mountable Adapter



Waterproof IP67 M12 X-code Poj Niam Jack rau RJ45 Poj Niam Jack yog compact thiab high-ceev cov ntaub ntawv kis tau tus mob connectors uas yog dav siv nyob rau hauv industrial daim ntaub ntawv. Cov adapters no yog tsim los muab kev ua haujlwm zoo thiab ua haujlwm ntev hauv qhov chaw hnyav.



Specifications



Khoom npe	M12 rau RJ45 Bulkhead Vaj Huam Sib Luag Mountable Connector
Connector 1	M12 Connector, poj niam, X code
Connector 2	Ethernet, poj niam
Rated Voltage	50V (AC) / 60V (DC)
Rated impulse voltage	800 V
Rated tam sim no	0.5 A
Tus nqi kis tau tus mob	TSI 6A
Kev ua raws li EMC	Tiv thaiv
raws tu qauv	EtherCAT, Profinet, Ethernet/IP
Coding interface	X-coded
Mount Hom	Vaj huam sib luag Mount, Tswj txee Mount, Flange Mount, Chasis Mount, Bulkhead vaj huam sib luag mountable



Qhov zoo

- Compact me me: Cov M12 rau RJ45 Adapters yog me me, ua rau lawv zoo tagnrho rau siv nyob rau hauv tsawg qhov chaw.

- Cov ntaub ntawv ceev ceev: RJ45 flange mount adapters muaj M12 X-coded connector uas ua kom cov ntaub ntawv xa mus ceev.

- Kev tiv thaiv zoo heev: Ethernet chassis mount adapters yog tsim los ntawm cov ntawv ci tooj liab thiab muaj cov molding sab hauv uas txhim kho cov nyhuv shielding los tiv thaiv electromagnetic cuam tshuam.

- Kub plating: M12 rau RJ45 ntsia hlau xauv connectors yog coated nrog kub, uas pab tiv thaiv oxidation thiab ua kom ntseeg tau kev ua tau zoo.



Daim ntawv thov



IndustrialNet M12 X-code rau RJ45 vaj huam sib luag mount adapter tuaj yeem siv rau hauv ntau daim ntawv thov kev lag luam, suav nrog:

- Kev tsim khoom
- Neeg hlau
- Automation
- Kev thauj mus los
- Roj thiab roj kev lag luam
- Kev ua zaub mov thiab dej haus
- Kev ua tshuaj lom neeg



Cim npe nrov: industrial m12 rau rj45 ethernet thiab ethercat pane mountable adapter, lwm tus neeg, manufacturers, hoobkas, customized, lag luam wholesale, quotation, dawb qauv
