BNC Chassis Connector D Shape
Qhov no BNC Chassis Connector D Shape yog ib qho kev sib txuas ua haujlwm siab tsim los rau kev lag luam audio thiab video. Nws siv cov tooj dag-machined precision los xyuas kom muaj kev sib txuas ruaj khov thiab tsis muaj hnav thiab ua tau zoo nyob rau hauv ob qho tib si high-frequency signal kis thiab hnyav ib puag ncig. Nrog lub plhaub D-zoo li tus, nws tuaj yeem ua rau hauv cov qauv vaj huam sib luag-mount XLR plhaub. Qhov no BNC D hom connector yog sib xws nrog Switchcraft's EH series thiab Neutrik's D series thiab haum rau ntau yam khoom siv suab thiab video thiab tshuab.
Specifications
| Khoom npe | Poj niam rau poj niam BNC vaj huam sib luag connector rau SDI thiab HDSDI signals |
| Daim duab No. | PCM-HD-0084 |
| Tshaj nrog | Switchcraft EH series thiab Neutrik D series |
| Txuas | BNC |
| Poj niam txiv neej | Poj niam mus poj niam |
| Chassis puab | D hom |
| Termination style | Feedthru |
| Mounting kev taw qhia | Pem hauv ntej mounting |
| Tiv tauj | tooj dag |
| Cov khoom siv tsev | PVC |
| Hom teeb liab | UHD, SDI, Video, AES/EBU, Composit, YUV, RGB, RGBH, RGBHV |
| Ntsia hlau | Ntsia hlau puag ncig lub taub hau, M3 L=10 00mm nickel plated |
| Txiv ntseej | Txiv ntseej ntxig, M3, npib tsib xee plated |
Nta
- Qhov no BNC Receptacle D-hom feedthrough yog tsim los raukev daws teeb meem siabvideo teeb liab kis tau tus mob thiab muabqis rov qab poobntawm high zaus.
- Nrog tus qauvD-shaped vaj tsev tsimuas tuaj yeem yooj yim ua rau hauv cov qauv vaj huam sib luag-mount XLR vaj tsev, BNC Poj Niam D-series Vaj Huam Sib Luag Mount Connector ua kom muaj ntau yam thiab yooj yim hauv kev teeb tsa.
- Siabsib haumnrog ib txwm siv BNC cable txuas, BNC chassis connector no tau sib xws nrog Switchcraft's EH series thiab Neutrik's D series, kom ntseeg tau tias siv dav hauv ntau lub tshuab.
- Nrog qhov tseeb75 Ω tsim, no BNC D Series Vaj Huam Sib Luag-Mount Connector lav kev ruaj ntseg thiab kev ntseeg siab hauv cov teeb liab kis tau tus mob.
Daim ntawv thov
Qhov Flange Mount D Hom BNC Poj Niam Feedthru Jack yog tsuas yog siv rau hauv cov khoom siv suab thiab video, tshwj xeeb tshaj yog nyob rau hauv lub sijhawm uas yuav tsum muaj kev daws teeb meem video teeb liab. Nws tuaj yeem ua lub luag haujlwm tseem ceeb hauv cov khoom siv tshaj tawm, kev soj ntsuam video, cov cuab yeej siv suab, thiab lwm yam kev siv uas yuav tsum tau muaj cov teeb liab ruaj khov thiab cov khoom sib txuas.
Tau tshaj
Tau tshaj cov qauv hauv qab no los ntawm Switchcraft's EH series thiab Neutrik's D series
NBB 75 DFGX
NBB75DFIX
NBB 75 DFG
NBB 75 DFGB
NBB 75 DFI
NBB75DFIB
NBB75DSGB
NBB 75 DSI
NBB75DSIB
NBB75DFIB-P
NBB 75 DSG
EHBNCCB
EHBNC2RB
EHBNC2B
EHBNCSC
EHBNC2R
EHBNC 2
EHBNC2BPKG
EHMBBNCUB
EHBNCUHD 2B
EHBNCRCAB
EHBNCMBBUHDB
EHMBBNCUHD
EHBNCUHD 2
