HSD Cable Sib Txuas Z Code Txoj Cai Lub Taub Hau rau Z Code Ncaj Jack
Puas yog koj tab tom nrhiav kev ua haujlwm siab, muaj kev ntseeg siab HSD cable sib dhos rau tsheb, kev lag luam lossis lwm cov ntaub ntawv xa xov hluav taws xob siab? Peb HSD cable sib dhos Z code txoj cai kaum sab xis rau Z code ncaj jack yog tsim los rau lub hom phiaj no. Nws siv lub Z code HSD connector, ib kawg yog ib tug ncaj plug (ncaj Jack), lwm kawg yog ib tug 90-degree luj tshib (Right Angle Jack), thiab txhua connector yog ib tug 4+2 Pin tsim, uas yog zoo meej rau ib puag ncig uas tsis muaj qhov chaw, yooj yim rau nruab thiab optimize thaiv layout. Nws yog dav siv nyob rau hauv automotive infotainment systems, tsav tsheb pab systems thiab high-txhais lub koob yees duab sib txuas.
Specifications
| Khoom npe | HSD cable 4+2 pin txoj cai kaum poj niam GPS telematics thiab navigation extension cable |
| Connector 1 | HSD connector, 4+2 tus pin, poj niam, ncaj, Z code, 99K11D-1D5A5-Y Rosenberger |
| Connector 2 | HSD connector, 4+2 tus pin, poj niam, 90-degree angled, Z code |
| Cable ntev | Customized |
| Hlau | Tshooj 535 |
| Pin suav | 6 (4 pins, 2 pins) |
| Impedance | 50Ω |
| Cov ntaub ntawv tus nqi | Mus txog 20 GHz |
| Tiv thaiv | 360˚ tag nrho tuag-casting shielded connector tsim |
| Kev khiav hauj lwm qhov kub thiab txias | -40 degree rau 85 degree, haum rau tsheb ib puag ncig |
| Kev sib haum xeeb | Ua haujlwm nrog hauv tsheb infotainment system, ADAS, navigation, koob yees duab, thiab lwm yam. |
HSD Connector Coding
Nta
- 4+2 Pin tsim, fais fab mov, thiab cov ntaub ntawv xa mus synchronization: Txhua qhov kawg yog 4+2 Pin configuration, uas tuaj yeem muab cov ntaub ntawv xa mus thiab cov khoom siv hluav taws xob tib lub sijhawm, haum rau cov khoom siv uas xav tau lub zog thiab cov teeb liab xa mus rau tib lub sijhawm. Txawm hais tias nws yog lub teeb liab daws teeb meem video lossis lub zog xa hluav taws xob, tus qauv 4+2 Pin tuaj yeem ua tau raws li koj xav tau.
- Flexibility thiab qhov chaw optimization: 90-degree lub luj tshib tsim ua rau cov txheej txheem kev teeb tsa yooj yim dua, tshwj xeeb tshaj yog tsim rau cov chaw teeb tsa nrog qhov chaw tsawg. Koj tuaj yeem yooj yim npaj cov hlua khi rau hauv qhov chaw me me kom txo tau cov kab congestion los yog khoov teeb meem.
- Kev thov dav: HSD txoj hlua hluav taws xob no tau siv dav hauv high-bandwidth cov ntaub ntawv kis tau tus mob xws li automotive infotainment systems (Infotainment), cov koob yees duab siab (xws li ADAS lub koob yees duab), navigation systems, thiab cov khoom siv sib txuas lus hauv tsheb kom tau raws li qhov xav tau ntawm kev sib txuas. ntau yam khoom siv hauv tsheb.
- Yooj yim rau customize: Peb muab cov kev pabcuam customization uas tuaj yeem kho cov hlua hlua ntev, cov qauv txuas, thiab hom cable raws li koj qhov kev xav tau kom haum rau koj cov kev xav tau tshwj xeeb.
